Galvanized Steel Conduit Pipe
Product Details:
- Coating Type Galvanized
- Flexibility Rigid
- Diameter Various diameters available
- Tensile Strength High tensile strength
- Tolerance Standard tolerance
- Product Type Conduit Pipe
- Material Galvanized steel
- Click to View more
X
Galvanized Steel Conduit Pipe Product Specifications
- Galvanized
- Standard length - 3 meters
- Electrical wiring protection
- Round
- Standard grade steel
- Rigid
- ANSI C80.1 / CSA C22.2
- Standard thickness
- Standard manufacturer warranty
- Electrical conduit applications
- Various options available
- Conduit Pipe
- Various diameters available
- High tensile strength
- Black
- Galvanized coating
- Circular
- Galvanized steel
- Standard tolerance
Product Description
Galvanized Conduits
ISI marked black stove enamelled Steel Conduit Pipes and Galvanized Steel Conduit Pipes are manufactured as per the following IS:9537 (Part II)/1981 dimensions.
| Nominal size of conduit (in mm) | Outside diameter (in mm) | Tolerance in outside diameter (in mm) | Wall thickness of conduit pipes (in mm) |
| 20 | 20 | -0.3 | 1.4 to 1.8 |
| 25 | 25 | -0.4 | 1.4 to 1.8 |
| 32 | 32 | -0.4 | 1.4 to 1.8 |
| 40 | 40 | -0.4 | 1.6 to 2.2 |
| 50 | 50 | -0.5 | 1.6 to 2.2 |
B.E.C also manufactures conduit pipes in various other colours such as Red, Green, Yellow, Blue, White or any colours as per requirement. In addition to this, GI conduits with epoxy coating are also manufactured for extra heavy protection for specific job requirements.
